8
PMC & eco-PMC SERIES FORCED DRAFT EVAPORATIVE CONDENSERS
Table 6 – Minimum “H” Dimension for Rigging Discharge Hoods and Discharge Attenuation
Rigging Hardware Parts List
The following table lists those parts which are shipped together with the unit(s) for field assembly.
(See Table 2 for model numbers corresponding to box size)
1
5/16” Diameter Hardware
(See Table 2 for model numbers corresponding to box size)
PMC-E, eco-PMC Dimensions
Box Size “H” Dimension
5’ Wide Models
5’ x 12’ 121”
5’ x 18’ 184”
10’ Wide Models
10’ x 12’ 121”
10’ x 18’ 184”
10’ x 24’ 121”
10’ x 36’ 184”
12’ Wide Models
12’ x 12’ 121”
12’ x 18’ 184”
12’ x 20’ 205”
12’ x 24’ (1) 121”
12’ x 24’ (2) 121”
12’ x 40’ 205”
Box Size Bolt1 Lock Nut1 Washer1 Sealer Tape
5’ x 12’ 14 14 28 3
5’ x 18’ 16 16 28 3
10’ x 12’ 14 14 28 4
10’ x 18’ 16 16 32 5
10’ x 24’ 28 28 56 8
10’ x 36’ 32 32 64 10
12’ x 12’ 14 14 28 5
12’ x 18’ 16 16 32 6
12’ x 20’ 16 16 32 6
12’ x 24’ (1) 28 28 56 10
12’ x 24’ (2) 28 28 56 10
12’ x 36’ 32 32 64 12
12’ x 40’ 32 32 64 12
Table 7 – Parts Shipped with Unit(s) by Box Size
