PMC & eco-PMC SERIES FORCED DRAFT EVAPORATIVE CONDENSERS
Table of Contents
Method of Shipment ........................................................................... 1
Storage ....................................................................................... 1
General ....................................................................................... 1
International Building Code Provisions ........................................................... 1
Structural Steel Support ........................................................................ 1
Rigging the Basin & Fan (Bottom) Section — Standard Li ........................................ 2
Rigging the Basin & Fan (Bottom) Section — Extended Li ........................................ 3
Applying Sealer Tape ..........................................................................4
Rigging the Heat Transfer Casing (Top) Section ...................................................4
Assembly of the Heat Transfer Casing (Top) Section to the Basin & Fan (Bottom) Section .............6
Optional Straight-Sided Hood Section ...........................................................7
Rigging Hardware Parts List .....................................................................8
Field Assembly of External Service Platform and Ladder ...........................................9
Final Assembly and Startup Details .............................................................10
Maintenance .................................................................................10
Notes ........................................................................................11
The PMC & eco-PMC SERIES FORCED DRAFT EVAPORATIVE CONDENSERS
should be rigged and assembled using the instructions and
recommendations outlined in this bulletin.
All personnel should review these procedures, as well as the latest industry-approved installation
practices, prior to rigging and assembly. The information in this bulletin is for informational purposes only.
These instructions do not purport to cover all variations and possible contingencies in connection with
installation. Additionally, the procedures described herein are subject to change without prior notice,
due to EVAPCO, Inc.’s ongoing research and development.
EVAPCO, Inc. makes no representations or warranties with respect to these instructions or the products
described herein. Nor shall EVAPCO, Inc. be responsible for any loss or damage (direct, indirect,
consequential, or other) during installation or handling of equipment aer shipment.
For a full description of EVAPCO’s liability policy, please visit www.evapco.com to access our Terms and Conditions.
