Evco c-pro 3 nano Series User Manual

EVCO S.p.A. c-pro 3 nano | Hardware Manual ver. 1.0 | Code 114CP3NE104
page 24 of 26
Auxiliary power supply:
If the device has a power supply of
12 VAC, 12 VDC +10% -15%, 120
mA max.
If the device has a power supply of
24 VAC/DC, 12 VDC, 120 mA max.
Ratiometric transducer power supply 5 VDC, +10% -15%, 20 mA max.
Digital inputs 2 dry contact and for pulse trains up
to 2 KHz
Up to 3, dry contact
Dry contact Contact type 3.3 VDC, 2 mA
Power supply None
Analogue outputs
2 for 0-10 V, PWM or phase cutting
signal
On request, 2 for 0-10 V, 0-20 mA or
4-20 mA signal
0-10 V
signal
Minimum applicable
impedance
1 KΩ
Resolution 0.01 V
PWM signal Power supply
0... 10 VDC (+16% -25%), 10 mA
max.
Frequency 10 Hz... 2 KHz
Duty: 0... 100%
0-20 mA
and 4-20
mA
Input resistance
40... 300 Ω
signal Resolution 0.05 mA
Digital outputs Up to 7 with SPST electro-mechanical
relay, 3 A res. @ 250 VAC
The device guarantees reinforced insulation between each digital output
connector and the rest of the components of the device.
Type 1 or Type 2 Actions Type 1
Additional features of Type 1 or Type
2 actions
C
Displays
Double custom display, 4 + 4 digit,
with function icons
Alarm buzzer Built-in
Communications ports
1 INTRABUS port (RS-485 MODBUS
master/slave by connecting the serial
interface EVIF22ISX)
According to the model, 1 RS-485
MODBUS master/slave port
According to the model, 1 CAN port 1 USB port
