Evco c-pro 3 NODE kilo+ - Page 19

EVCO S.p.A. c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
NO5 usually open contact for digital output 5 (electromechanical relay with 3 A res. @ 250 VAC)
NO6 usually open contact for digital output 6 (electromechanical relay with 3 A res. @ 250 VAC)
CO7 common digital output 7
NO7 usually open contact for digital output 7 (electromechanical relay with 3 A res. @ 250 VAC)
NC7 usually open contact for digital output 7
CO8 common digital output 8
NO8
usually open contact for digital output 8
according to model:
- electromechanical relay with 3 A res. @ 250 VAC
- control for 24 VAC/DC, 600 mA max. solid state relays
CO9 common digital output 9
NO9
usually open contact for digital output 9
according to model:
- electromechanical relay with 3 A res. @ 250 VAC
- control for 24 VAC/DC, 600 mA max. solid state relays
CO10 common digital output 10
NO10 usually open contact for digital output 10 (electromechanical relay with 3 A res. @ 250 VAC)
CO11 common digital output 11
NO11 usually open contact for digital output 11 (electromechanical relay with 3 A res. @ 250 VAC)
NC11 usually open contact for digital output 11
CAN/RS-485
RS-485 MODBUS slave, RS-485 MODBUS master/slave and CAN CANBUS ports
The communication protocol for the RS-485 MODBUS master/slave port can be set with the UNI-PRO 3 development environment.
For the settings for the RS-485 MODBUS slave, RS-485 MODBUS master/slave and CAN CANBUS ports, please refer to chapter 6
“CONFIGURATION”.
PART MEANING
CAN+ CAN CANBUS port positive pole
CAN- CAN CANBUS port negative pole
GND RS-485 MODBUS slave, RS-485 MODBUS master/slave and CAN CANBUS ports ground
A1/+ RS-485 MODBUS master/slave port positive pole
page 19 of 55
