EVCO S.p.A. c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
Digital inputs NTC (10 K @ 25 °C, 77 °F)
Type of sensor: NTC type 2.
Measurement field: from -40 to 86 °C (from -40 to 186 °F).
Precision: ±1 °C.
Resolution :0,1 °C.
Conversion time: 100 ms.
Protection: none.
Digital inputs NTC (10 K @ 25 °C, 77 °F)
Type of sensor: NTC type 3.
Measurement field: from -40 to 86 °C (from -40 to 186 °F).
Precision: ±1 °C.
Resolution :0,1 °C.
Conversion time: 100 ms.
Protection: none.
Digital inputs Pt 1000 (1 K @ 0 °C, 32 °F)
Measurement field: from -100 to 400 °C (from -148 to 752 °F).
Precision: - ±0,5 % of scale end from -100 to 200 °C
- ±2 °C from 200 to 400 °C.
Resolution :0.1 °C.
Conversion time: 100 ms.
Protection: none.
Digital inputs 0-20 mA and 4-20 mA
Input resistance: ≤ 200 .
Precision: ±0.5 % of scale end.
Resolution :0.01 mA.
Conversion time: 100 ms.
Protection: none; maximum allowable current at each input is 25 mA.
Digital inputs 0-5 V raziometrici and 0-10 V
Input resistance: ≥ 10K .
Precision: ±0.5 % of scale end.
Resolution :0.01 V.
Conversion time: 100 ms.
Protection: none.
Digital inputs:
13 inputs (configurable through the UNI-PRO 3 development environment for NA or NC
contact):
- 2 at 24 VAC/DC, 50/60 Hz/2 KHz opto-isolated; the frequency can be set
through the UNI-PRO 3 development environment
- 11 at 24VAC/DC 50/60 Hz opto-isolated.
Digital inputs at 24 VAC/DC, 50/60 Hz
Power: - 24 VAC (±15 %), 50/60 Hz (±3 Hz)
- 24 VDC (+66 %, -16 %).
Input resistance: ≥ 10K .
Protection: none.
