Rear-facing
The Anti-rebound Bar is for use REAR-FACING ONLY.
NEVER use the Anti-rebound Bar in Forward-facing
or Booster Modes.
WARNING
2726
Using the Child Restraint
Rear-facing
Child Requirements:
• Weight: 1.8 to 22.6 kg (4 to 50 lbs)
• Height: 43 to 122 cm (17 to 48 in.) and top of child’s
head is at least 2.5 cm (1 in.) or more below the
bottom of the headrest adjust lever
When using this restraint rear-facing, DO NOT loosen the
vehicle seat belt to provide more leg room as this may keep
the child restraint from protecting your child.
IMPORTANT: Once your child exceeds any of the size
requirements above, they MUST use this child restraint in
the forward-facing orientation, if possible. If your child
exceeds any of the size requirements above and is less
than 2 years old, however, you MUST discontinue use of
this child restraint.
2.5 cm (1 in.) or more
Harness straps
are AT or JUST
BELOW the
child’s shoulders.
Rear-facing
Belt Path
Lower
Anchor (UAS)
Connector
Assembly
WARNING
DO NOT install by
this method for a
child weighing more
than 18kg (40lbs).
Place Anti-rebound Bar through slots in seat cover into
metal tubing in seat shell.
Press the locking buttons and insert Anti-rebound Bar until
both ends click into place.
Note:
Pull the Anti-rebound Bar
to make sure it is locked securely.
1.
anti-rebound bar is REQUIRED for rear-facing
use in Canada.
Using the Anti-Rebound Bar -
Rear-facing Only
2.
To remove the Anti-rebound Bar, press both locking buttons
and withdraw the Bar from the seat.
1
2
3
4
5
PLACE
AT
ARMPIT
1
2
3
4
5
PLACE
AT
ARMPIT
CLICK!
Anti-rebound
Bar
Anti-rebound
Bar
To Next Page
