27
Positioning the Crotch Strap
As your child grows, you will need to change the crotch
strap position so that it is in the slot closest to your child.
The crotch strap should ALWAYS be as close as possible
to, but NEVER under, the child’s bottom.
IMPORTANT: You MUST place the crotch strap in the
front slot if your child weighs 18 kg (40 lbs) or more.
2.
Insert Crotch
Strap into new
slot.
Insert the crotch strap
anchor into the slot
that is the closest to
the child AND the
most comfortable for
the child.
Pull the crotch strap to
make sure it is secure.
1.
Remove Crotch
Strap.
Loosen the harness
straps and move them
out of the way.
Push the anchor up
through the slot to
the top of the seat
.
Using with the 5-pt Harness
To Next Page
