78
LATCH/UAS (Rear-Facing and Forward-Facing)
Installing LATCH/UAS
6. Squeeze handle on LockStrong belt
tensioner until lock indicator turns
RED, then lift up on belt tensioner to
allow access to the belt path.
7. Attach LATCH/UAS Connectors
to vehicle Lower Anchor Bars.
Connectors will make an audible
CLICK when attached. Make sure
they are attached by pulling rmly
on connectors.
NOTE: If your Revolve360
is equipped with Mini-Latch
connectors, DO NOT pull on red
Release Strap.
CLICK!
