Evenflo REVOLVE360 User Manual

92
Booster Mode (Forward-Facing Only)
Installing the Booster
4. Squeeze handle on LockStrong belt
tensioner until lock indicator turns
RED, then lift up on belt tensioner to
allow access to the belt path.
5. Attach LATCH/UAS Connectors
to vehicle Lower Anchor Bars.
Connectors will make an audible
CLICK when attached. Make sure
they are attached by pulling rmly
on connectors.
NOTE: If your Revolve360
is equipped with Mini-Latch
connectors, DO NOT pull on red
Release Strap.
CLICK!

Evenflo REVOLVE360 Specifications

General

Type	Convertible Car Seat
Rotation	360-degree rotation
Rear-Facing Weight Capacity	4-40 lbs
Forward-Facing Weight Capacity	22-65 lbs
Harness	5-point harness
Headrest Positions	10
Safety Standards	FMVSS 213
Side Impact Protection	Yes
Machine Washable Cover	Yes
Installation	LATCH or seat belt
