Removing Child from the Restraint
buckle
storage
buckle
storage
Press the red buckle release
B
, and remove the buckle
tongues.
2
3
Press the adjuster release
button
A
to loosen harness
strap.
When the lower anchor connector system is not in use,
you MUST attach each hook
A
, or clip
B
, onto the
base
G
. Be sure the lower anchor connector straps are
tucked completely inside the seat shell. A loose lower
anchor connector strap and hook may injure your child.
1
Loosen the harness strap
by pressing the tension
release button
C
located
on the front of the seat.
While pressing the
button
C
, pull up on
the harness straps
D
near
the child’s lap.
A
2
A
G
G
B
3
To remove the hook
B
,
press the tab
C
and twist,
then remove from anchor
D
.
B
D
To remove the clip
E
,
pull the red release strap
F and remove clip from
anchor
D
.
C
E
D
F
To unfasten the chest clip, push the release button
A
and pull apart.
A
buckle
storage
buckle
storage
B
Removing the Lower Anchor
Connectors
4
To easily remove your
child, unbuckle the crotch
buckle and insert the
buckle tongues into the
buckle tongue holders
E
on each side of the
restraint.
Not available on all
models.
E
E
