Knob Functions – Secondary Parameters
Out Lvl
Chop
“Chopping” Tremolo
LFO: Off, Triangle, Saw, Ramp,
Square, Random Sample/Hold
Auto-volume FX: Volume Swell,
Trigger extreme gating,
CW = increased sensitivity
Rear Panel
Power
9VDC center-negative
Mono/Stereo Switch
Left = Mono (TS plug)
Right = Stereo (TRS plug)
I
n Stereo, Tip is OUT1, Ring is OUT2
I/O Level Switch
Left - Guitar
Right - Line/Effects Loop
EXP
Connect Expression Pedal,
Auxiliary Switches or TRS MIDI
(See System Setup)
Mini USB
Software updates
& MIDI over USB
OUT1 & OUT2
In Mono, both outputs have
the same dry signal
Spd/Rise/Rel
Chop parameter control
LFO, SPD controls LFO Rate
SWL, Rise controls rise time
TRG, Rel controls release time
Predelay
Time before 1
st
Tap
1 sec max
Boost/Cut output level
Center for unity gain
Tone
Turn left for dark,
right for bright taps
IN
Standard TS (mono)
or TRS (stereo)
Slurm
Tap slurring/smearing/
modulation
Press button to toggle
Secondary/Primary parameters
