OPERATING INSTRUCTIONS
Note: Before the unit can be operated, it must either be ducted or, if the model is installed as a re-circulating
range hood, it must be fitted with charcoal filters.
Connect the plug into the power.
Below is a diagram of the light and fan functions, with an explanation of how the light and the fan functions
operate.
To operate the light, push the switch ① into “I” position to switch the light on, or into “0” to turn the light off.
To operate the fan, push the switch ② onto either:
I – Low Fan Speed
II – Medium Fan Speed
III – High Fan Speed
0 – To turn the fan Off.
If your range hood does not function correctly when attempting any of the above, please ensure that your
power is on and is functioning correctly. If the power seems to be functioning correctly in the house, there
may be a problem with the range hood. Please call your authorized service agent in this case to organise a
service call or replacement unit.
REPLACING THE BULBS
MODELS RUES51 & RUES71
1. Switch the unit off and disconnect from mains power first.
2. Remove filter and read labels regarding maximum lamp ratings.
3. Press the light face and remove by turning in anti-clockwise
direction.
4. Pull out the halogen light bulb carefully and replace by same type
and same rated halogen light bulb (12V 40W MAX).
5. Push back into the unit and fix in place by rotating clockwise.
CHARCOAL FILTER INSTALLATION
1. Turn the appliance off and disconnect from the power
source.
2. Remove the filter.
3. Place the charcoal filters (CF110) on either end of the
motor and fix by rotating clockwise.
4. Replace the filter and connect the power.
6
