24
EF 5500
12V
EF 5500
24V
EF 7000
12V
EF 7000
24V
POWER CONNECTION
Mains power
12 V 24 V 12 V 24 V
Max. input power (W) 202 180 240 228
Max. input (A) 16,8 7,5 20 9,5
Protection fuse (A) 20 15 25 15
HYDRAULIC CONNECTION
Max. water supply temperature (°C - °F)
60 - 140
Min. water supply temperature (°C - °F) 5 - 41
Min. water supply ow rate (l/min - USgpm) 28,4 - 7,5 37,1 - 9,8
Max. water supply pressure (bar - psi) 1,0 - 15
Max. priming depth (m - ft) 2,5 - 8,0 3,0 - 9,0
PERFORMANCE
Max. ow rate (l/min - USgpm)
20,8 - 5,5 26,5 - 7,0
Flow rate at max. pressure (l/min - USgpm) 15,2 - 4,0 19,7 - 5,2
Max. pressure (bar - psi) 4,1 - 59
Max. level of sound pressure - uncertainty (dB(A)) 73 - 0,8
WEIGHT (kg - lb) 2,5 - 5,6 4,3 - 9,5
IDENTIFICATION OF COMPONENTS
Refer to Figures from 1 to 5 at the beginning of the manual.
1. Suction
2. Delivery
3. Feet
4. Identication plate
5. Fuse holder cover
6. Power connector
MOTOR PUMP IDENTIFICATION PLATE
WARNING
• Should the identication plate deteriorate during use, contact the Manufacturer or a Skilled Technician to
have it restored.
The identication plate (4) shows the motor pump model, the serial number, the year of manufacture and
the main electrical and mechanical specications (max. ow rate, max. pressure, power supply voltage,
input, etc.). It is located on the motor pump casing.
SAFETY DEVICES
a) Pressure switch.
This device, suitably calibrated by the Manufacturer, limits the maximum operating pressure, preventing
hazardous pressure levels, when the delivery is closed or when trying to set pressure values above the
maximum permitted ones.
Specications and details are approximate.
The Manufacturer reserves the right to make all changes to the motor pump deemed necessary.
