1.6.6 Set alarm parameters
Alarm Setting Menu
CH SENSOR
1 N.O.
2 N.O.
3 N.O.
4 N.O.
ALARM RESET IN : N.O.
BUZZER : ON
KEY LOCK : OFF
ALARM HOLD TIME: 05 SEC
CH1 - CH4 to set the sensor input type as
'N.O.' : normally open, closed will invoke alarm
'N.C.' : normally closed, open will invoke alarm
'closed' means to short the alarm signal line to the ground
ALARM RESET IN : To set alarm reset input type as 'N.O.' or 'N.C.'
BUZZER : Turn the buzzer ON/OFF
KEY LOCK : Turn the KEY LOCK function ON or OFF when key lock is turned on
1. All keys except SET key are locked
2. KEY LOCK stays ON until we turn it OFF by pressing the SET key
ALARM HOLD TIME : It is the time period of buzz if the buzzer is on.
