2.1 Alarm out
There are two ways to do the alarm out connection:
2.1.1 Normally Open Connection (use pin # 1 and # 9)
8
2 1
15 9
COIL
EverPlex 4CQ
Alarm out
RELAY
2.1.2 Normally Closed Connection (use pin # 1 and # 2)
8
2 1
15 9
COIL
EverPlex 4CQ
Alarm out
RELAY
