* Telescopic Rails
Telescopic rails allow you to pull tray and internal grill easily.
Telescopic rails, which are provided to you as an ac-
cessory, can be mounted on the side wire racks eas-
ily with two pieces of holding clips. Since there are
right and left rails, make sure that you know which
rail you shall install on which side. Check the right
(R) and left (L) signs on the rails.
Our installation recommendation is that you should
take the side wire racks completely out of the oven
and install the telescopic rails on the side wire racks
on a at surface. Install the telescopic rail on the
upper one among the two racks. The rails can be
easily mounted and demounted. After adjusting the
positions of right and left telescopic rails, press on
them until they are inserted into the side wire racks.
Check whether the rails are seated completely or
not by looking behind the wire rack.
After installing the telescopic rails, mount the wire
racks into the oven again. Do not use the wire grill
just below the rack on which the telescopic rail is
xed.
L
Left
Front
Left telescopic rail
Rear
R
Right
Front
Right telescopic rail
Rear
