Installation Instructions 9
Type Eversol-TL2100 Eversol-TL3200 Eversol-TL4600 Eversol-TL5400
Weight 19.9 kg 20.7 kg 21.4 kg 23.5 kg
5.1.2 Ambient conditions
1. The area where the units installed is as dry as possible in order to extend their
service life.
2. Ensure good access to the unit for installation or any service work that may later
be required.
3. Maintain the following minimum clearances around the unit:
4. If the wall is wooden, please add a thermal insulating layer between Eversol
inverter and the wooden wall.
5. Do not expose the Eversol to direct sunlight, in order to avoid power reduction
due to excessive heating. That the ambient temperature keeps below 40
o
C will
guarantee the Eversol working in optimal status.
6. Provide better ventilation for Eversol to ensure that heat is dissipated adequately.
7. Install Eversol on a solid surface. Because of the noises made by the Eversol
when in operating, do not install the unit on plasterboard walls in order to avoid
audible vibrations.
Direction Minimum clearance
above 30 cm
below 30 cm
sides 30 cm
