Eversys E4-2020 - Page 39

3 modules - Shotmaster s-pro | Shotmaster ms-pro
W
D
(with large drip tray)
H
D
Description Shotmaster s-pro Shotmaster ms-pro
Weight - Super Traditional line 163 kg 167 kg
Dimensions - Super Traditional line (W x H x D) 849 x 743 x 667 mm (33.4 x 29.2 x 26.2 in)
Dimensions with large drip tray - Super Traditional line
(W x H x D)
849 x 743 x 717 mm (33.4 x 29.2 x 28.2 in)
Brew chamber 4 x 24 g
Grinder 4 x
Ceramic burrs - 64 mm
Display 3 x Touch screens
256 mm (10.1") - 1280 x 800 px
Bean hopper 4 x 1.5 kg
Coee outlet height* Max. 190 mm
Hot water outlet height* 160 mm or 215 mm (option)
Interfaces 4 x USB, 2 x Ethernet, 2 x CCI/CSI
Cup heater Up to 64 espresso cups
Coee boiler 4 x 1.5 L
Steam boiler 5.4 L
Grounds drawer 2 x 700 g
Drip tray Large or Standard (option) or Large with pitcher
rinsers (option)
*measured from the drip tray
For more information, refer to Options (page 130).
Description
02.01.2023 Page 39 of 172 © Eversys S.A.
