EVGA BQ User Manual

05
Dimensions: 86mm (H) x 150mm (W) x 165mm (L)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
650 / 750 / 850 BQ Cable Configuration
Modular Connector Connector Per Cable Cable Qty
MB ATX 20+4-Pin x 1
1
CPU1
VGA2,VGA3
Hard Lined
SATA1,SATA2,SATA3
PERIF1,PERIF2/FDD Molex 4-Pin x 3 + FDD x 1
1
650 BQ
EPS/ATX12V 8(4+4)-Pin x 1
1
PCI-E 6-PIN + 8(6+2)-Pin x 1
1
SATA 5-Pin x 3
SATA 5-Pin x 4
1
1
PCI-E 6-PIN + 8(6+2)-Pin x 1 1
VGA1
Modular Connector Connector Per Cable Cable Qty
MB ATX 20+4-Pin x 1
1
CPU1
VGA2,VGA3
Hard Lined
SATA1,SATA2,SATA3
PERIF1,PERIF2/FDD
Molex 4-Pin x 2
Molex 4-Pin x 3 + FDD x 1
1
1
850 BQ
EPS/ATX12V 8(4+4)-Pin x 1
1
PCI-E 6-PIN + 8(6+2)-Pin x 1
1
1
SATA 5-Pin x 3
SATA 5-Pin x 4
2
1
PCI-E 6-PIN + 8(6+2)-Pin x 1
2
VGA1
Modular Connector Connector Per Cable Cable Qty
MB ATX 20+4-Pin x 1
1
CPU1
VGA2,VGA3
CPU2
CPU2
Hard Lined
SATA1,SATA2,SATA3
PERIF1,PERIF2/FDD
Molex 4-Pin x 3 + FDD x 1
Molex 4-Pin x 2
1
750 BQ
EPS/ATX12V 8(4+4)-Pin x 1
EPS/ATX12V 8(4+4)-Pin x 1
EPS/ATX12V 8(4+4)-Pin x 1
1
PCI-E 6-PIN + 8(6+2)-Pin x 1
1
1
SATA 5-Pin x 3 3
1
PCI-E 6-PIN + 8(6+2)-Pin x 1
2
VGA1

EVGA BQ Specifications

General

Form Factor	ATX
Modularity	Semi-Modular
Efficiency Rating	80+ Bronze
Series	BQ
MTBF	100, 000 Hours
Molex Connectors	3
SATA Connectors	6
PCI-E Connectors	2
Protection	OVP, UVP, OPP, SCP, OTP
Warranty	3 years
Maximum Power	600W, 750W, 850W
