EVGA Z370 MICRO User Manual

EVGA Z370 MICRO (121-KS-E375)
- 34 -
Connecting Cables
Note: the following images do not necessarily represent the
physical orientation of their respective headers on the EVGA Z370
MICRO. Instead, these graphical representations are designed to
provide a basic physical footprint and the cable pinouts for each
component.
The locations of these components can be found in the Component
Legend on Pages 11-12.
This section takes you through all the necessary connections on the
motherboard. This will include:
 Power Connections
24pin ATX power (PW1)
EPS 8-pin 12V power
6-pin PCIe power
 Internal Headers
Front Panel connectors (Power/Reset/LEDs)
PWM Fan Headers
USB 2.0 Header
USB 3.0 Header
Audio Header
SATA
 Rear I/O Panel

EVGA Z370 MICRO Specifications

General

Brand	EVGA
Model	Z370 MICRO
Category	Motherboard
Language	English
