EVOCA Kalea - Page 39

01-2018 5035 01 31
1
2
3
4
5
6
Fig. 25
1. Fresh Brew nozzle
2. Upper piston
3. Espresso nozzle
4. Infusion chamber
5. Scraper
6. Lower piston
volumE of tHE iNfusioN cHambEr
Brewing unit doses
Z4000 ESFB (∅ 46) 7 - 14 g
The upper piston automatically positions
itself according to the desired selection
(espresso or fresh brew).
