25
Please follow the procedure below to validate your routine cleaning:
Repeatedly running the adhesive card through the printer cleans the cleaning rollers in order to maintain print quality and extend the service life of the print
head.
1 Open the printer cover.
2 Remove the ribbon as shown on the diagram.
3 Close the cover and check it has clicked shut.
4 Open the card feeder.
5 Using the gauge, set the card thickness to the MAX position.
2
3
4
1
5
To Next Page
