Evolis Primacy Lamination - Page 61

PRIMACY
LAMINATION
61
Card positioning
Magnetic stripe cards must be placed in the card feeder so that the magnetic stripe is facing downwards as shown below:
1 Open the card feeder as shown.
2 Insert up to 100 magnetic cards maximum, of 0.76 mm. Ensure the cards are positioned as illustrated in the diagram (magnetic stripe
on the right).
3 Close the feeder.
1 2 3
