TEMPEST FILTER OVERVIEW
1½"
OUTLET
1½"
INLET
1½"
Slide Valve
(Inlet)
1½"
Slide Valve
(Outlet)
K+Media
(Floats to
top during
operation)
Air Inlet
Cover Cap
1½" Pipe Clip
Bracket
1½" Pipe Clip
Bracket
1½"
Connector
Pipe
1½"
Connector
Pipe
TO WASTE
1" HOSETAIL
Waste
Valve
Assembly
