Evolution Aqua Tempest - Tempest Filter Specifications; Technical Data and Dimensions

6
TEMPEST FILTER SPECIFICATIONS
INLET 1½” (UK / USA) / 50mm (EU)
OUTLET 1½” (UK / USA) / 50mm (EU)
DRAIN HOSETAIL SIZE 1” (UK / USA) / 32mm (EU)
MAXIMUM FLOW RATE 7,500 LPH / 1,650 GPH / 1,980 US GPH
OPTIMUM FLOW RATE 5,000 LPH / 1,100 GPH / 1,320 US GPH
K+MEDIA SUPPLIED 7 Litres
WATER VOLUME IN FILTER 27 Litres / 5.9 Gallons / 7.1 US Gallons
The Tempest filter can also be used on quarantine systems or as a standalone
filter on smaller ponds up to 5,000 litres / 1,100 gallons / 1,320 US gallons.
1100mm
790mm
Centre of pipe to centre of pipe
250mm
130mm
45mm
105mm
205mm
PUMP
IN
AIR
INLET
WASTE
VALVE
OUTLET
TO
POND
