6
www.evolutionpowertools.com
SPECIFICATIONS
MACHINE METRIC IMPERIAL
Motor (UK) 230V ~ 50/60Hz 1200W 5A
Motor (UK) 110V ~ 50/60Hz 1200W 11A
Motor (USA) 120V ~ 60Hz 1200W 10A
Number Of Speeds 1 1
Speed (No Load) 570min
-1
570rpm
Insulation Class 1 1
Power Cord Length 2.6m 8’ 5”
Weight 14kg 31lb
CUTTER CAPACITIES
Maximum Annular Cutting Capacity 28mm 11/8”
Maximum Cutting Depth 50mm 2”
Cutter Shank 19mm 3/4”
Standard Twist Drill Capacity 13mm 1/2”
MAGNET
Magnetic Adhesion 1300kg f 2860lbs f
Minimum Plate Thickness 10mm 3/8”
DIMENSIONS
Magnet Dimension 50 x 80 x 164mm 2 x 3-1/8 x 6-1/2”
Maximum Machine Height 585mm 23”
Minimum Machine Height 450mm 17-3/4”
Machine Width 225mm 8-7/8”
NOISE & VIBRATION
Sound Pressure Level L
PA
85.10 dB(A) K=3 dB(A)
Sound Power Level L
WA
98.10 dB(A) K=3 dB(A)
Hand Arm Vibration 0.283m/s
2
K=1.5m/s
2
MODEL NUMBERS
United Kingdom 230V: 090-0001 110V: 090-0002
United States 090-0003
Europe 090-0004
