VEHICLE MAINTENANCE
Be familiar with vehicle features before attempting any operations.
D3 Lifted User’s Manual Page45.
1
2
BRING THE VEHICLE BACK TO SERVICE FROM STORAGE
1. Fully charge the battery.
2. Set the Forward /Reverse control (DNR) to N.
3. Adjust the pressure in each tire to the recommended tire pressure.
4. Have a trained technician lubricate the vehicle.
5. Do a daily pre-operation safety checklist.
6. Do a vehicle performance inspection.
JOBS TO BE DONE PRIOR TO THE STORAGE
>Put golf cart under shelter, keep the golf cart in dry and ventilated space.Optimal temperature
14°F to 95°F (-10°C to 35°C) . Maximum storage temperature should not be higher than 122 °F
(50°C).
>Turn the key switch to the OFF position, remove the key and leave the forward/reverse switch
in the NEUTRAL position during storage.
>Power down all accessories.
>Clean the battery packs, tops and terminals using a battery acid neutralizer (1 cup baking
soda per 1 gallon water).Check, clean and treat battery terminal connections with a battery
terminal protector spray.
>Disconnect batteries per ensuring that the cables do not come into contact with a terminal
(Disconnect the 48V Main power outlet cables from battery pack ,insulate the cable ) .
>Connect Battery cables back to system, charge the battery to full state every 1-3 months to
keep battery alive without damages caused by over-discharging.
>Perform all semi-Annual Lubrications .
>Thoroughly clean the front and rear body ,seats ,battery compartment and underside of the
vehicle.
>DO NOT engage the park brakes , but secure the golf cart from rolling. Chock the wheels with
wheel stopper or something similar .
>Check Tire pressure and inflate the tires to standard pressure level as values presented on
tires.
>Thoroughly clean the front and rear body ,seats ,battery compartment and underside of the
vehicle.
