BATTERY CHARGER
Be familiar with vehicle features before attempting any operations.
.BATTERY CHARGER
D3 Lifted User’s Manual Page34.
1
2
WARNING
INCORRECT CONNECTION OF THE AC CORD CAN CAUSE A FIRE OR AN ELECTRICAL
SHOCK. DO NOT USE AN ADAPTER TO CONNECT THE AC CORD INTO A TWO-PRONG
POWER SOURCE. CONNECT THE AC CORD TO AN APPROVED POWER SOURCE.
CONNECTION OF THE AC CORD TO AN INCORRECT RECEPTACLE CAN CAUSE A FIRE,
ELECTRICAL SHOCK, PROPERTY DAMAGE, SERIOUS PERSONAL INJURY, OR DEATH.
CONNECT THE AC CORD TO AN APPROVED POWER SOURCE AND RECEPTACLE. DO NOT
LET THE BATTERY CHARGER BECOME WET. KEEP THE BATTERY CHARGER DRY.
CHARGER SPECIFICATION
Battery pack rated voltage
Maximum charger ouput
AC input voltage range
AC input current value
48V
68V
85-270VAC, 45-65Hz
11.5A@120VAC, 6.1A@220VAC
Power factor
Charger efficiency
Noise
IP Class
Weight
Operating temperature
Storage temerature
0.99
95%
45dB
IP67
9.3Ib (4.2kg)
-86
To Next Page
