Evolution RAGE3+ User Manual

Fig. 1a
RED
WHITE
Fig. 1b
Fig. 1c
KNOW THE PARTS
The 3 main component parts to be assembled are:
 (Fig. 1a)
 (Fig. 1b)
 (Fig. 1c)
7
www.evolutionpowertools.com

Evolution RAGE3+ Specifications

General

Bevel Capacity	45°
Weight	5.9 kg
Bore	25.4mm
Max. Box Section (Wall Thickness)	3mm
Bevel Range	0° - 45°
