Also to be fitted are:
(Fig. 2a)
(Fig. 2b)
(Fig. 2c)
(Fig. 2d)
Note: One of two types of Mitre Locking Handle will be
supplied, according to the machine purchased. Only the
short mitre locking handle requires the spacer.
(Fig. 2a) Fit the spacer over the threaded mitre locking
handle before installation. (Short mitre locking handled
machines only)
WARNING:
be fitted after the assembly process is completed and the mitre
saw has passed the Assembly Safety Checks.
See Assembly Safety Checks list on page 16.
Fig. 2a
Fig. 2b
Fig. 2c Fig. 2d
ANTIVIBRATION SPRING
LONG MITRE
LOCKING
HANDLE
SHORT MITRE
LOCKING HANDLE
SPACER
8
