Evolution UC-33 Advanced User Guide
10
The 14 assignable buttons can each be assigned to toggle between two values. You
may for instance want to send out value 15 when you first press the button followed by
value 74 when you press the button for a second time. This is how you do it:
1. Press the Function button labelled DATA MSB 2 times.
2. Type in 15 using the numerical keypad or the +/- keys.
3. Press the Function button labelled DATA LSB 2 times.
4. Type in 74 using the numerical keypad or the +/- keys.
If you want the button to send the same value every time you press it, simply type in the
same value both times.
As already described, the standard MIDI controller numbers range from 0 to 131. We
have extended the list of MIDI cc's that can be assigned to the controllers of the UC-33
to include RPN/NRPN, MMC and General MIDI 1&2 SysEx messages.
These advanced messages are as easy to program as a regular MIDI cc instruction by
entering values 132 to 152 when programming MIDI cc’s. The charts on page 8 and 9
(or Appendix B) show you what number correspond to each message
To program the values required for these advanced messages, the UC-33 requires you
to press the PROGRAM, DATA LSB and DATA MSB buttons twice respectively.
Pressing only once will send the program and bank change instructions “on the fly” as
described earlier.
Lets look at a couple of examples to see how this works. Please refer to the chart in
Appendix B so you get to grips with the principle:
1. Select the button you want to control the MMC message.
2. Press “ASSIGN” on the UC-33.
3. Type in “149” using the numerical keypad.
This is the number that correspond to the MMC instruction, as per the chart on
page 8 and 9.
4. Press “Channel” once.
5. Type in “127”, using the numerical keypad.
This ensures that the message is set to all device ID numbers. For more
information about this, please read “About SysEx Messages & Device ID”
on page 13.
4. Press the “DATA LSB” button twice.
5. Enter a number from the chart on the next page to select the MMC
message you want:
Setting Toggle Values For The Buttons
RPN/NRPN, GM 1+2 SysEx & Other Messages
Assigning MMC Control To A Button
