Evolution UC-33 Advanced User Guide
12
1. Press SELECT and press the “0” button. The display will show that you
have selected controller 34.
2. Press ASSIGN and enter '147' this is the MIDI CC
number that corresponds to Note on/off mode, as shown in
Appendix B.
3. Press DATA MSB twice and enter a value of '100'. This means
when you press the button, a Note on message will be sent
out with a velocity of 100.
4. Press DATA LSB twice, and enter a value of '000'. This
means when you release the button, a Note off message will
be sent out.
5. Press the PROGRAM button twice and enter '064'. This will
mean you are sending out MIDI note 64 or E4, each time you
press the button. The MIDI note numbers are given in
Appendix D.
This button mode has many uses. You can use this mode to trigger
samples, control lighting equipment, play keyboard notes and much more.
Note: When you press the button in note mode, the LCD display will briefly
show the note velocity.
When transmitting SysEx messages, the individual control channel number does not
define a transmit channel, but a device ID. This is made clear since when you press
the CHANNEL button, the CC symbol will not be shown and there is no ’c’ in the 3
digit display.
Device ID’s range between 00 – 127. In most cases, you should set the device ID as
127. 127 means the SysEx message will be received by all devices.
Please note that the device ID for a Sys Ex message assigned to a controller can not
be changed using the Device ID buttons. These buttons are used for varying the
global device ID of the UC33.
