4 ) Change the CCTV screen: Display of CCTV 1 and CCTV 2 screens.
- This function cannot be used when only one camera is connected.
5 ) Video storage: Saving a video clip.
- When you press the button, storage starts.
- The icon below will be displayed while saving images. The remaining time will b
e
d
isplayed at the top right.
- To stop the storage, touch the icon.
6 ) Saving images: Saving a static cutout.
- When you touch the button, you can save images. And the icon below will be
during storage.
Click on the screen image area to enter the video quality settings menu:
Change brightness/contrast/chromaticity.
S
ettings: (Outdoor unit and CCTV have the same settings.)
1 ) The video cannot be saved unless an SD card is inserted.
- Images can be saved in the monitor's built-in memory (max. 50 files).
- If you need to back up images that are stored in the monitor's built-in memory,
you can use the procedure below.
1.1) Turn on the monitor and then insert the SD card. Turn on the monitor. Images
are then automatically saved to the SD card. (Images are automatically deleted after
backup.)
1.2) You can check the files through your computer ([backup folder] on the SD card).
1.3) You can check the date, time of saving and information (recording source,
saving format, emergency saving).
- File name: YYMMDD_HHMMSS_AB.AVI or JPG
Remark: Meaning of the last two digits (marked AB)
A: 1 - DVEŘE1 / 2 - DVEŘE2 / 3 - CCTV1 / 4 - CCTV2
B: 1 - MANUAL (manual recording)/2 - AUTO/3 - MOTION/4-ALARM
ex: Meaning of film '230109_045740_12.avi'
-> Video automatically recorded by visitors calling from door 1 on January 9, 2023 at
4:57:40 pm.
2 ) The picture and video clip can be stored while the SD card is inserted. Th
e
m
aximum storage size depends on the capacity (storage size) of the SD card.
INTERCOM
When you touch the Intercom button, the connected monitor is called up and the
following screen is displayed.
