20
SF1000 / SF2200e Inverter Generator Owner’s Manual
CAUTION
Generator is heavy! Obtain assistance to lift the
generator to avoid back or other bodily injury.
Engine Oil
Engine Oil
6. Place the oil pan, or other container suitable for hold-
ing engine oil, in front of the generator.
9. Return the unit to the upright position.
10. Remove the oil drain pipe.
11. Using a clean cloth, wipe around the drain plug area
to remove any dirt and debris.
12. Fill the oil fill container (included) with the appropriate
amount and type of new (unused) oil. (See Figure 17
for recommended oil type.)
SF1000 SF2200
Oil Capacity [qt / ml]
0.26 / 250
0.48 / 450
FIGURE 23: Oil Drain Pan
TABLE 5. Engine Oil Capacity
13. Slowly pour oil into the oil fill hole. DO NOT OVER-
FILL.
7. Remove the oil fill cap.
FIGURE 26: Adding Engine Oil
14. Check the oil level is up to the innermost thread of the
crankcase.
FIGURE 24: Oil Fill Cap Removal
8. Attach the oil drain pipe (do not over tighten) and tilt
the generator allowing the oil to completely drain into
the oil pan.
FIGURE 27: Oil Fill Measurement
FIGURE 25: Drain Oil (SF2200 Model)
