Evopower SF1000 - Specifications

SF1000 / SF2200e Inverter Generator Owner’s Manual
www.evopower.co.uk
29
SPECIFICATIONS AND WIRING DIAGRAMS
Model SF1000 SF2200
DIMENSIONS
Length [in / mm] 18.1 / 459.7 21.3 / 541
Height [in / mm] 15.1 / 383.5 20.0 / 508
Width [in / mm] 9.6 / 243.8 11.4 / 289.6
Dry Weight [lb / kg] 30 / 13.6 58 / 26.3
POWER OUTPUT
Rated (AC) [watts] 900 2000
Rated (DC) [watts] 60 100
Frequency* [hertz] 60 60
Voltage (AC)* [volts] 120 120
Voltage (DC)* [volts] 12-18 12-18
OPERATING TEMPERATURE
Maximum [F / C]
104 / 40 104 / 40
Minimum [F / C]
14 / -10 14 / -10
ENGINE
Speed [rpm]
5400** 5000**
Type OHV 4-cycle OHV 4-cycle
Displacement [cc]
53 125
Fuel Tank Capacity [gal / L]
0.7 / 2.6 1.5 / 5.7
Engine Oil Capacity [qt / ml]
0.26 / 250 0.48 / 450
Spark Plug Gap [in /mm]
0.024-0.028 /
0.6-0.7
0.024-0.028 /
0.6-0.7
* Under load
**Efficiency switch in OFF position
TABLE 10. SF1000 / SF2200 Inverter Generator Specifications
