stripped end of 9 inch anode cable through items 5, 6
and 8 of clear plastic encased splice. NOTE – either
end of encased splice can be used since both ends
are identical.
7. Insert the stripped end of #14 gauge, single
conductor wire going to the CAPAC
®
Controller
through items 9 and 10 of clear plastic encased
splice.
8. Butt splice anode wire to #14 gauge single conductor
wire going to the CAPAC
®
controller using butt
connector (item 7). Crimp and soft solder connector
as shown in Figure 3.1. Thread the ribbed nuts (items
5 and 10) onto the treaded tube (item 8) and tighten.
REFERENCE ELECTRODE INSTALLATION
& PARTS LIST
Parts List
Reference Electrode Assembly Complete -37800
Item#
Fig. 3.1
Quantity Part Number Description
1 1 37802 Reference Electrode Assembly
2 1 37795-9-1 Flat Washer
3 1 37344-13 Lock Washer
4 1 37791-25-1 Hex Nut
5-10 1 37798 Encased Splice
10 feet 37292 Butyl Bead
Reference Electrode Installation (See Figure 3.1)
The reference electrode silver-silver chloride element is 2-1/2 inches in
diameter and is supported and electrically insulated from the hull by the back
plastic structure, which surrounds it. The treaded stem serves to mount the
reference electrode as a through-hull fitting. Water tightness is insured by the
butyl sealant and the electrical connection is protected by the clear plastic
To Next Page
