Controller Specifications
Operating voltage 12V DC
Automatic Control Range 380 Millivolts to 1.3 Volts
Current Output 0 to 7.5 Amperes
Control sensitivity
±9.929V from control point
Type of Control Smoothly Varying
Weight 3.5 lb.s
Active Components 1-CA3130 Integrated Circuit
1-2N4037 Transistors
3-2N1711 Transistors
1-2N3054 Transistor
1-2N3771 Transistor
