3.Installation

3.1. PreparingtheProductforInstallation

Before installing the frame, please take the following steps:

• Check the product for any visible damage that may have occurred during transit.

• Confirm receipt of all products on the packing list.

• Retain the original packaging for possible re-use.

Please refer to section 1.2 "Unpacking and Shipping" on page 1 for more information about returning a

product for servicing or replacement.

Please contact your EVS dealer if parts are missing or damaged or when products on the

packing list are missing.

3.2.Unpacking

The Neuron frame must be unpacked and installed in an anti-static environment. Make sure all

packaging material on the outside and the inside of the frame is removed before bringing it into

operation.

3.3.Modulelayout

In general, a Neuron processing module layout appears as shown in the diagram below. The module

consists of a metal baseplate, an I/O backplate and a PCB with connectors. Indicated in the diagram are

the most important parts of a Neuron processing module.

INSTALLATION AND SERVICE MANUAL

Neuron NFR2001|3. Installation| 7
