Power

NPU0501 Input

(specification @ 25°C) Nominal input: -48VDC (-40V ... -60V DC)

Input capacitor: 200uF

Output

Max. output power: 500W

Output voltage: +12V DC

Tolerance: +/- 1% (120mV)

Ripple/Noise: 250mVpp

Load Range: 0 .. 500W

Fuse: 250V / 15 A fast – (not serviceable)

Max. power per slot: 200W

Each PSU is fused internally (not customer serviceable).

Cooling

Fans 4 fans in each PSU

Required air volume for maximum cooling capacity 290 M3/h

EnvironmentalConditions

Operating temperature 0º to 30º C environmental temperature (32º to 86º F)

Storage temperature -20º to 70º environmental temperature (-4º to 158º F)

Humidity Up to 95% relative humidity, non-condensing

INSTALLATION AND SERVICE MANUAL

Neuron NFR2001|4. Specifications| 13
