Maximum Cable Lengths
The following table specifies the maximum cable lengths depending on the cable type,
and the SDTInetwork speed. The 540Mbps is only supported up to Multicam 10.04.
Cable Type @ 2970 Mbps @ 1485 Mbps @ 540 Mbps
RG59 30 m / 98 ft 45 m / 148 ft 100 m / 328 ft
RG6 70 m / 230 ft 100 m / 328 ft 180 m / 590 ft
RG11 85 m / 279 ft 120 m / 394 ft 250 m / 820 ft
Fiber 55 km * 80 km * 200 km *
* 55km/80km/200km is the total length of the return path, i.e. the actual distances
between the 2 servers connected via the fiber link is half of this value, i.e. 40 km @ 1485
Mbps.
Note
When using reclockers, the total delay induced by these reclockers between 2
active servers on the network must not exceed 15μs.
8 2. Hardware
EVS Broadcast Equipment SA Issue 4.00.B- June 2014
