Left View
2.2. Front Panel
Overview
# Element
1. Status LED
2. Speed LED
3. Branch Status LEDs
4. Master / Slave switch
5. Version switch
6. USB port (B type)
7. Power switch 1
8. Power switch 2
Status LED
The Status LED will flash green when the XHub3 is in operation.
TECHNICAL REFERENCE MANUAL XHub3 4.00
2. Hardware 3
