3
Internal View
SMD810 Instruction Manual - W4386A
Entry Gland Plate
for Load Cables
Circuit Breakers and
Emergency Lighting Line Outputs
Dimmed or
Switched 230V Outputs
40A Single Phase
Supply Connections
4 x Side Entry
Gland Knockouts
DALI Broadcast,
1-10V or DSI
Control Ouputs
Earth Link
Accessory Port
SceneSelect
Bus Terminations
Low Voltage
Cable Gland
Network
Socket
Service LED
Service Switch
