SMD810 Instruction Manual - W4386A
9
Troubleshooting
Specification
SYMPTOM
Dimmer does not operate at all. No Service LED
activity. Power supply indicator LED on PCB not lit.
Power supply indicator LED lit, but no Service LED
activity.
Dimmer will not respond to control panel push
buttons.
Dimmer operates properly but circuit breakers keep
tripping.
Fluorescent lights won’t dim.
PROBABLE CAUSE
Incorrect connection of mains supply, or no power
available.
Supply voltage too low, short circuit on network.
Control PCB faulty.
Control panel incorrectly wired or incorrect
configuration.
Instant tripping:- short circuit on load.
Delayed tripping:- dimmer overloaded.
Wrong type of ballast or ballast incorrectly wired.
ACTION
Check power supply to dimmer. Check Line and
Neutral input connections.
Check supply voltage is at least 75% of rated
voltage. Check 5V & 12V terminal voltages, 5V
supply must be present. Disconnect network bus
and restore power. Replace control PCB.
Check operation of LEDs on control panel. Push
button on panel and study response of service LED.
Check load wiring for short circuits. Verify dimmer
loading with current tester (don’t forget to de-rate for
low power-factor loads and transformer losses).
Check that the breaker terminals are tight.
Check ballast type. Check actual wiring against
ballast manufacturer’s diagram. Check 1-10V/DSI
settings.
Check the following list. If you are still unable to rectify the situation, contact Ex-Or. Please ensure that you have completed the following
prior to calling our technical support department.
l
Check all symptoms in the Troubleshooting list
l
Check for any deviations between the installation and the installation instructions
l
Make a list of the model numbers of all devices used in the system
Supply: 230V, 50Hz single phase at 40A
Outputs: 4 x 10A dimmed (leading edge phase control) at 10A each
4 x 10A switched outputs
4 x HF ballast control outputs selectable to 1-10V DC, DSI or DALI broadcast
Protection: 4 x 10A 6kA single pole thermal magnetic circuit breakers
Regulating Device: Triac 600V, 40A nom. 400A surge
Switching Device: Relay 16A nom. up to 800A surge
Power Conditioning; Regulated outputs
Over voltage protection
Surge protection
Brownout/Sag protection
Spike protection
Soft Start
16 bit fade resolution (65535 steps)
Interference Suppression: Iron powder toroidal choke
Rise Time: 100µS at 230V
Control Inputs: 1 x SceneSelect bus serial port
1 x programmable dry contact AUX input
User Controls: Service Switch
Diagnostic LED
Override switch - All channels to 100%
Internal Controls: Programmable Logic Controller
SceneSelect Bus DC Supply: 200mA (supply for approximately 8 Control Panels)
Preset Scenes: 170
2
Supply Terminals: Live, Neutral 2 x 10mm max conductor size
Output Terminals: Live, Neutral for each channels 1-8
2
2 x 4mm max conductor size
Earth link bar provided
0V/DSI/DALI (broadcast) , +V/DSI for channels 9-12
2
1 x 2.5mm max conductor size
Cable Entries: Mains 8 x 25mm dia. knockout
Data 1 x 25mm dia. knockout
Compliance: CE, C-Tick
o
Ambient Temperature: 40 C max.
Construction: Alloy/Steel wall mount case with epoxy finish
Dimensions: Height 370mm x Width 215mm x Depth 170mm (excludes wall brackets)
Weight: 7.5 Kilograms (packed weight)
