Exalto CT3N User Manual

- Exalto Wiper Technologies type CT3N
4
1. General
CT3N is an electronic wiper control system for up to five motors. CT3Nn is composed
by one control panel and one relay box. The control panel and the relay box are con-
nected by an CAT5 cable (CAN Bus cable).
1.1 Features
• Double voltage supply: 12V - 24V
• Activates/deactivates each wiper one by one
• Synchronization in every mode
• Three (four with one speed motors) intermittent settings
• Dynamic brake
• Wipe/wash program
• Single wipe function
• Heater activation (additional relay box required)
• Selection of backlighting color and brightness
• Fault and error signaling
1.2 Standard supply
• 1 x Control panel
• 1 x Relay box
• 1 x 5 meter cable or CAN Bus connection
• 1 x 4-poles female connector for Relay box to motors connection
(1 for each motor)
• 1 x female 6,3mm fast-on terminal for washing pump connection
• 2 x (or 4 if more than 3 wipers) female 9,5mm fast-on terminal for power supply
connection
1.3 System conguration
Model No. of wipers Control panel Relay box Art. code
CT3N2 2 210321224.P 210321224.R 210321224
CT3N3 3 210331224.P 210331224.R 210331224
CT3N4 4 210341224.P 210341224.R 210341224
CT3N5 5 210351224.P 210351224.R 210351224
If user need two stations, wire up the adding panel (optional) via CAN BUS to the
relay box.
