5.8 Use of the folding backrest
The folding backrest
To lower the height of the wheelchair for transporting you can fold down the
backrest in the following way:
 Stand behind the wheelchair;
 Squeeze both black levers at the back of the wheelchair, picture 14 at the same
time to fold down the backrest;
 The folding mechanism is now unlocked, you can fold down the backrest, see
picture 15.
 Make sure the backrest is straight up before taking place in the wheelchair;
 To put the backrest straight up you should follow the above steps in reversed
order.
Picture 14
Figuur 11
Picture 15
