Excel G-Lite Pro - Wheelchair Components and Functionality; Components of the Wheelchair

~ 5 ~
User manual
© 2013 VAN OS MEDICAL UK Ltd., Excel House, Escrick Business Park, Escrick,
York,YO19 6FD Tel. +44-(0)1904-720170, Fax +44-(0)1904-720398,
E-mail: sales@vanosmedical.com,
www.vanosmedical.com
2 GENERAL EXPLANATION OF YOUR WHEELCHAIR
2.1 Components of the wheelchair
1
Backrest pad flip over
9
Front castor
2
Height adjustable armrest
10
Bearing house
3
Seat pad flip on
11
Stepper
4
Footrest
12
Brake
5
Cross frame
13
Hand rim
6
Heel strap
14
Rear wheel
7
Footplate
15
Fixation lever for fordable backrest
8
Front wheel
16
Push handle
Your wheelchair is equipped with a number of elements and parts. You should know
these before continue reading this manual. Designs and specifications may change
without prior notice.
