4.1 Control units
Controle panel:
Speed button
With the speed button you can adjust the minimum and maximum speed;
Turn the knob against the clock for lower speed;
Turn the knob clock wise for a higher speed;
We advise you to adjust your speed as high as you think is comfortable.
Horn
Press this button to horn.
Emergency light
When you press this button all the light will turn. Press one more time to turn it off.
Lever forward and backwards
Pull the right lever to drive forwards;
Pull the left lever to drive backwards.
