PARTS LIST & EXPLODED VIEW
PRESSURE WASHER ITEM # E104480
ITEM KIT #
PART
NO.
QTY DESCRIPTION ITEM KIT #
PART
NO.
QTY DESCRIPTION
1 E104107 1 Assm, Hose, 15 Foot, 20MPA
Pressure Rating
23 E104588 1 Weldmend, Tubing (Front, Base)
- Vette
2 E104577 1 Panel, Accessory - Vette 24 E104573 1 Foot, Plastic - Vette
3 6 Screw, M6x1.0x16 SBHCS 25 E104574 1 Tank, Chemical - Vette
4 6 Washer, Lock M6 26 4 Bolt, M8x1.25x25 SBHCS
5 6 Washer, Flat 6MM - 18.5MM OD 27 4 Washer, Lock 8mm
6 E104126 5 Grommet, Nozzle 28 4 Washer, Flat 8mm X 19mm
7 E104112 1 Nozzle, 0 Degree Red 29 E104575 1 Cap, Chemical Tank - Vette
8 E104114 1 Nozzle, 15 Degree Yellow 30 E104063 2 Bolt, Saddle M8x45
9 E104115 1 Nozzle, 40 Degree White 31 E104064 2 Knob, Five Prong
10 E104598 1 Nozzle, 25 Degree - Green 32 6 Screw, #8-16x.75 Pan Head
Plastite T20
11 E104113 1 Nozzle, Low Pressure Black 33 E104587 1 Cover, Pump Bottom - IC2
12 E104591 1 Assembly, Handle - Vette 34 1 1 Pump, IC2
13 E104430 1 Assembly, Engine, 180cc RATO,
R180-3
35 1 1 Shaft, Couple Spline
14 E104811 1 Gun, Pressure Washer, BIT 101 36 1 1 Screw Set 5/16-24 X.438 SM DG
PT
15 E104102 1 Assy, wand & quick connect,
15.125 inch
37 4 Bolt, SHC, M8 X 1.25 X 20MM
16 2 Nut, M8x1.25 Nyloc 38 E104586 1 Cover, Pump Top - IC2
17 2 Washer, M8 - 30 OD 39 1 E104788 1 Injector, Chem, 1.8mm, Fixed,
JE#4343
18 E104611 2 Wheel, 10" Pneumatic 40 1,2 1 Nut, Swivel, Garden Hose
19 E104054 2 Spud, Wheel (Short) 41 1,2 1 Swivel, 3/8 NPT Male
20 4 Nut,M8X1,Serrated Flangehead 42 1 E104787 1 Screen, 3/4 Garden Hose
21 2 Screw, M6x1.0x10 Hex 43 E104141 1 Chemical Hose
22 4 Bolt, M8x1.25x35 Hex Serrated
Flange
KIT NUMBERS, DESCRIPTIONS, AND INCLUDED
COMPONENTS ARE LISTED BELOW:
KIT #
ORDER
NO.
DESCRIPTION
COMPONENT
REFERENCE #
1 E104797 Kit, Assy IC2 34-36, 39-42
2 E104789 Kit, Swivel 40-41
• Note: Any part number eld without a number listed is
not available
• Descriptions are provided for reference only.
To Next Page
