Exerpeutic Elliptical - Parts List

No.
Description
Qty
No.
Description
Qty
001
Main Frame
1
022L
Left Foot Pedal
1
002
Front Stabilizer Ø60x1.5tx510mm
1
022R
Right Foot Pedal
1
003
Rear Stabilizer Ø60x1.5tx590mm
1
023A
Lower Crank Cover A (Black)
2
004
Front Post Ø60x2.0tx975mm
1
023B
Lower Crank Cover B (Black)
2
005
Handlebar Ø32
1
024
Belt Pulley Ø220
1
006L
Upper Left Handrail Ø32
1
025
Belt Pulley Ø180
1
006R
Upper Right Handrail Ø32
1
026
Handrail Foam Grip
Ø32x5tx750mm
2
007L
Left Handrail Arm Ø32
1
027
Handlebar Foam Grip
Ø32x3tx380mm
2
007R
Right Handrail Arm Ø32
1
028
Flywheel Ø200
1
008
U Shape Bracket
2
029
Magnet Bracket
1
009L
Left Foot Bar
1
030
Handlebar End Cap Ø32
2
009R
Right Foot Bar
1
031
Handrail End Cap Ø50
2
010
Crank
2
032
Hexagon Socket Head Bolt
M8x15mm
2
011
Computer
1
033
Hexagon Socket Head Bolt
M8x15mm
8
012
Computer Wire L=1050mm
1
034
Carriage Bolt M8x70mm
4
013
Tension Control
1
035
Cap Nut M8
4
014
Tension Control Cable
1
036
Washer Ø8xØ16x1.5T
8
015
Extension Sensor Wire
L=1250mm
1
037
Belt Pulley Shaft Ø12x90mm
1
016
Hand Pulse Sensor
2
038
Curve Washer Ø21xØ8x2t
10
017
Hand Pulse Sensor Wire
L=600mm
2
039
Hexagon Socket Head Bolt
M8x42mm
4
018
Washer Ø8xØ38x2.0T
2
040
Nylon Locknut M8
7
019
Front Stabilizer End Cap Ø60
2
041
Hexagon Socket Head Bolt
M10x80mm
2
020
Rear Stabilizer End Cap Ø60
2
042
Washer Ø10xØ19x1.5t
3
021L
Left Cover
1
043
Carriage Bolt M6x45mm
4
021R
Right Cover
1
044
Nylon Locknut M10
4
PARTS LIST
6
