Exerpeutic Pro Stride 21 - Assembly Instructions; Front Stabilizer Installation

1. Front Stabilizer Installation
Place a block of wood to raise the main body for easier to install the Front
Stabilizer (9).
Position the Front Stabilizer (9) in front of Main Frame (1) and align bolt holes.
Attach the Front Stabilizer (9) onto the front curve of the Main Frame (1) with two
3/8"x64mm Bolts (35), four 3/8"x20x2.0T Washers (36), and two 3/8"x17T Cap
Nuts (37). Tighten bolts with the Hex Tool with Phillips Screwdriver provided.
Hardware:
ASSEMBLY
10
(35) Bolt 3/8"x64mm
2 PCS
(36) Washer 3/8"x20x2.0T
4 PCS
(37) Cap Nut 3/8"x17T
2 PCS
Hex Tool with Phillips
Screwdriver (14mm)
Tool:
Block of Wood
